香港电子器材有限公司
高级会员第2年 参观人数:94170
  • 参考报价:电议
    型号:
    产地:美国
    在线咨询
  • 详细介绍:


    Standford Research SR810锁相放大器SR830锁相放大器以合理的成本提供高性能。 SR830同时显示信号的幅度和相位,而SR810只显示幅度。

    两种仪器都使用数字信号处理(DSP)来代替传统锁相中发现的解调器,输出滤波器和放大器。

    The SR810 Lock-In Amplifier and SR830 Lock-In Amplifier provide high performance at a reasonable cost. The SR830 simultaneously displays the magnitude and phase of a signal, while the SR810 displays magnitude only.

    Both instruments use digital signal processing (DSP) to replace the demodulators, output filters, and amplifiers found in conventional lock-ins.

    ·1 mHz102.4 kHz频率范围

    ·> 100 dB动态保留

    ·5ppm /℃的稳定性

    ·0.01度相位分辨率

    ·10μs30 ks的时间常数(高达24 dB / oct滚降)

    ·自动增益,相位,-reserve-offset

    ·合成参考源

    ·GPIBRS-232接口

    • 1 mHz to 102.4 kHz range

    • >100 dB dynamic reserve

    • 5 ppm/°C stability

    • 0.01 degree phase resolution

    • Time constants from 10 μs to 30 ks(up to 24 dB/oct rolloff)

    • Auto-gain, -phase, -reserve and -offset

    • Reference source

    • GPIB and RS-232 interfaces
