品牌: | 森茂 |
产地: | |
关注度: | 5226 |
型号: | XSG系列 |
干燥介质:其它
适用物料:多种可用
操作方式:自动
XSG 系列快速旋转闪蒸干燥机
XSG Series Flash Dryer
◆
热空气切线进入干燥器底部,在搅拌器带动下形成强有力的旋转风场。膏状物料由螺旋加料器进入干燥器内,在高速旋转搅拌桨的强烈作用下,物料受撞击、磨擦及剪切力的作用下得到分散,块状物料迅速粉碎,与热空气充分接触、受热、干燥。脱水后的干物料随热气流上升,分级环将大颗粒截留,小颗粒从环中心排出干燥器外,由旋风分离器和除尘器回收,未干透或大块物料受离心力作用甩向器壁,重新落到底部被粉碎干燥。
◆
The hot air enters into the bottom of the dryer in tangent direction.Under the driving of the stirrer, a powerful rotating wind area is formed.The paste state materials enter into the dryer through the screw charger. Under the powerful effect of stirring at high-speed rotation, the materials are distributed under the function of strike, friction and shearing force. The block state materials will soon be smashed and
contact the hot air fully and the materials are heated and dried. The
dried materials after the de-watering will go up with the hot-air flow.
The grading rings will stop and keep the big particles. Small particles
will be discharged out of the dryer from the ring center and will be
collected in the cyclone and dust collector. The not-fully-dried or big
piece materials will be sent to the wall of the equipment by centrifugal
force and be smashed again after they fall down to the bottom.
旋流、流化、喷动及粉碎分级技术的有机结合。
设备紧凑,体积小,生产效率高,连续生产,实现了“小设备、大生产”。
干燥强度大,能耗低,热效率高。
物料停留时间短,成品质量好,可用于热敏性物料干燥。
负压或微负压操作,密闭性好,效率高,消除环境污染。
This machine combines the whirl technology with the fluidity, ejection and smashing step technologies.
The equipment is compact and small in size, high in production efficiency and continuous in the production. It has realized
that " small equipment can perform the large production".
The drying capacity for this machine is big but its energy consumption is low. Its heat efficiency is high.
The material stay time is very short. The quality of the final products is very good. The machine can be used for drying the
heat sensitive materials.
For the negative pressure or the micro-negative pressure operation, the machine is good for its tightness and high in the
efficiency so as to eliminate the environmental pollution.
